Industrial PRO Fog 70B Mist Pump

Industrial PRO Fog 70B

6XFEGT6WT1

Solutions

Dust Suppression, Odour Control, Cooling, Climate Control, Greenhouse Humidification, Landscape and Special Effects

Product Highlights

  • Medium to large areas - 12 - 470 nozzles
  • Pump flow - 1 l/min to 42 l/min
  • Suitable for aggressive environments
  • Connects to external control devices
  • New safety system detects pipe breakage
  • Solutions: Cooling, Dust Suppression, Humidification, Odour Control

Areas of Application:

Animal Breeding Farms
Bulk Material Handling
Construction Sites
Cooling Animal Enclosures
Electric power Stations
Factory
Fin Fan Cooling
Greenhouse
Industrial Sites
Landscaping
Mine Sites
Piggeries
Plant Propagation
Rainforest Effects
Recycling Facilities
Sport Stadiums
Theme Parks and Ride Special Effects
Timber
Warehouses



Industrial PRO Fog 70B High pressure pump

For fogging systems from 12 to 470 nozzles.

The Industrial PRO Fog 70B Series

is designed for any fogging system project and size. With flow rates ranging from 1 l/min up to 42 l/min, it is ideal for use in both commercial and industrial sites: for humidification, dust suppression, odour control, personnel cooling, outdoor cooling and fog effects.

Equipped with connection for external devices such as thermostats, humidistat and duty cycle. Also available in a stainless steel version (head pump, solenoid valve and by-pass) making it suitable for corrosive environments where the use of reverse osmosis or chemical solutions is required.

NEW SAFETY SYSTEM: Automatic shut-down of system when pipe breakage on the high pressure fog line is detected. This prevents flooding where the lines are installed.

Industrial PRO Series high-pressure pumps are combined with flexible nylon tubing or stainless steel mist line, industrial-rated wall fans, or a combination of both.

CoolMist offers completely customised pumps and systems for a wide variety of applications that feature custom controls to suit specific needs.


Technical Details
No. of Nozzles: 12-470 nozzles
Pressure (bar): 70bar
Flow Rate (L/min): 1 to 42L/min
Pump Features:

HP pump with crankshaft, 3 pistons, brass head (standard version), stainless steel AISI 316 L head (SS version)

Recommended Accessories:
  • Polyamide pipe line ø9.6mm -3/8" and nickel-plated brass fittings
  • Grilamide pipe line ø9.6mm-3/8" in AISI 316 stainless steel
  • Fog nozzles
  • Fog nozzles - accessories and special fittings
  • Dosing pump
  • Pause / Work Time Control, Humidistat or Temperature Control options
